| Reference |
5960 |
596005 |
| MAIN FEATURES |
Digital Processing Technology |
Yes |
Scan & Log w/ automatic channel
identification |
Terrestrial / CATV |
Yes |
| Satellite |
Yes |
| Universal Auto Lock. DVB-T, DVB-C, DVB-S&S2 |
Yes |
| Q.A.L. (QPSK Auto Lock) |
Yes |
| Interfaces |
HDMI, USB, SD card, Mini-DIN, CAM, FC/APC (F.O.) |
| USB SW update |
Yes |
| Latest version HW & SW |
Yes |
| Thumbwheel navigation |
Yes |
| Satellite frequency selection |
IF, real RF, channel, and memory |
| Units |
dBμV, dBmV, dBm, dBμV/m |
| Power-saving auto shut off (1- 59 min.) |
Yes |
| Power-saving auto suspended mode (1- 59 min.) |
Yes |
| Languages |
English, Spanish, German, French, Italian, Portuguese, Russian, and Polish |
| Menu and measurement display |
On-Screen-Display (OSD) |
| Teletext |
Analog & Digital |
| One screen measurements |
Yes |
| Pass/Fail Indicators |
Yes |
| Real-time COMBO mode |
Yes |
| Dynamic Range |
Terrestrial / CATV |
60 dB |
| Satellite |
55 dB |
| Fiber Optics Interface |
Yes |
| HDMI output |
Yes |
| Ethernet remote control and measurements |
598903 opt. |
| SPECTRUM
ANALYZER |
SPAN |
Terrestrial / CATV |
100, 200, 500kHz, 1, 2, 5, 10, 20, 50, 100, 200, 500 MHz, 1, 1.5, 2GHz & FULL |
| Satellite |
100, 200, 500kHz, 1, 2, 5, 10, 20, 50, 100, 200, 500 MHz, 1, 1.5, 2GHz & FULL |
| RBW |
Terrestrial / CATV |
300, 600Hz, 1.5, 3, 6, 12, 24,100, 200, 400, 800kHz, 1.6, 3.2MHz |
| Satellite |
200, 400, 800KHz, 1.6, 3.2MHz |
| BER measurement in spectrum mode |
Yes |
| Reference level |
User-selectable: 1, 2, 5, and 10 dB |
| Overload alarm |
Yes |
| Real time sweeping speeds |
< 10 ms |
| Display refresh |
< 100 ms |
| MAX/min hold mode |
Yes |
| Markers |
3 |
| Spectrum analyzer Zoom |
Yes |
| Two trace display |
Yes |
| Event trigger |
Yes |
| Background noise display |
Yes |
| Digital Signal sampling detectors |
Yes |
| User-selectable VBW |
Yes |
| Automatic satellite ID |
Yes |
WORKFLOW
AUTOMATION |
Memories |
1000 |
| Macros |
Yes |
| Datalogs |
100 macros w/ 250 memories each |
| Log capacity |
Yes |
| SD card |
Up to 30,000 |
| Outlet type selection |
Yes |
| Installation/Outlet datalog classification |
Yes |
| Instant Logs |
Yes |
| Graph Logs |
Yes |
| HSuite |
Data Logger |
Yes |
| Graph Logger |
Yes |
| Pass/Fail indicators configuration |
Yes |
| BANDS |
Return channel (5-47 MHz): DVB-T, DVB-C & analog |
5 to 3,300 MHz continuous band |
| Terrestrial/CATV (47-880 MHz): DVB-T, DVB-C, DVB-H & analog |
DVB-T2 598901 opt. |
| FM radio (80-110 MHz) |
Yes |
| GSM (880-950 MHz): Spectrum mode measurements |
Yes |
| Satellite (950-2,220 MHz): DVB-S & DVB-S2 |
Yes |
| Wi-Fi (2,220-2,500 MHz): Spectrum mode measurements |
Yes |
| Extended spectrum analyzer (2,500 – 3,300 MHz) |
Yes |
| ANALOG
MEASUREMENTS |
Level |
Yes |
| Level and C/N triggered audio alarm |
Yes |
| Automatic C/N |
C/N 52 dB |
| Line C/N |
Yes |
| Field Strength |
Yes |
| Automatic C/N |
Yes |
| CTB/CSO |
Yes |
| HUM |
Yes |
| Sync pulse representation |
(Terrestrial) |
| Video line representation |
Yes |
| Standards |
PAL B/G, D/K, I, SECAM B/G, D/K, L, NTSC |
| Input range |
-15 to 130 dBμV |
|
Power level |
-15 to 130 dBμV |
| Automatic C/N |
Yes |
| Referenced C/N |
Yes |
| Level and C/N triggered audio alarm |
Yes |
| COFDM echoes representation |
Yes |
Constellation display: DVB-T (user-selectable carrier),
DVB-T2 (598901 opt.), DVB-C, DVB-S2 (8PSK or QPSK) |
Yes |
| Packet Error Rate |
Yes |
| NICAM |
Yes |
| DIGITAL
MEASUREMENTS |
DVB-T |
cBER |
9.9E-2 to 1.0E-6 |
| vBER |
1.0E-4 to 1.0E-8 |
| MER |
> 35 dB |
| PWR |
40 to 125 dBμV |
| Automatic offset detection |
Yes |
| DVB-T2 (598901 only) |
Link Margin |
-1 to 10dB |
| LDPCBER |
1.0E-2 to 1.0E-6 |
| BCHBER |
9.9E-2 to 1.0E – 8 |
| MER |
> 35dB |
| PWR |
40 to 120 dBμV |
| Automatic offset detection |
Yes |
| DVB-C |
BER |
9.9E-2 to 1.0E-8 |
| MER |
> 38dB |
| AUTO Attenuation |
Yes |
| PWR |
40 to 125 dBμV |
| Symbol Rate |
AUTO, (700 to 7200 kbaud) |
| DVB-S (w/ Q.A.L. technology) |
cBER |
1.0E-2 to 1.0E-6 |
| vBER |
1.0E-4 to 1.0E-8 |
| MER |
Yes |
| PWR |
40 to120 dBμV |
| Symbol Rate |
AUTO, from 1 to 45 Mbaud |
| Code Rate |
AUTO, 2/3, 3/4, 5/6, 7/8, 1/2 |
| DVB-S2 |
Link Margin |
(- 8.3) to 20 dB |
| cBER |
1.0E-2 to 1.0E-8 |
| BCH BER |
5.0E-2 to 1.0E-8 |
| MER |
Yes |
| AUTO Attenuation |
Yes |
| PWR |
40 to120 dBμV |
| Symbol Rate |
AUTO, 1 to 30 Mbaud |
| Code Rate |
AUTO (supporting 1/4, 1/3, 2/5, 3/5, 1/2, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10) |
| OTHERS |
Optical |
Wavelength |
1310 nm, 1490 nm, and 1550 nm |
| Attenuation |
Yes |
| CWDM channel |
– |
Yes |
| RF |
RF Attenuation |
Yes |
| TILT |
Yes |
| MPEG |
Free-to-Air MPEG-2 SD decoder |
Yes |
| Free-to-Air H.264 HD decoder up to 1920×1080p (Full HD) |
Yes |
| Number of services, selected service, audio services |
Yes |
| NID, VPID, APID, SID (w/ Network Descriptor) |
Yes |
| Video resolution, audio type, language |
Yes |
| HD identification |
Yes |
| CAM module (MPEG-2 only) |
Yes |
| LNB FEED |
Power feed w/extra burst (14, 19.5V to compensate long cable runs) |
13/18/24 V – 13 + 1/18 + 1/24 V (Extra Burst) |
| 22 kHz tone switch |
Yes |
| DiSEqC & SCR |
Yes |
| BATTERY |
Type / Autonomy |
Litio-ION (over 4 hours from a full charge in low-consumption mode) |
| Energy management: Normal, Low Consumption & Auto |
Yes |
| Battery status indicator (w/ screen icon and audio beep) |
Yes |
